DJI Agras T50 M3 Aircraft Arm
Official DJI parts diagram and material list.
Pricing is per single item unless the part description says otherwise.
All T50 assemblies (15)
Parts Diagram
Hover a number to match it with the list. Double-click or use + to zoom.Tap a number to jump to it in the list. Use + to zoom in.
| No. | Part | $ Each (inc. GST) | |
|---|---|---|---|
| 1 | Three Phase Cable Sealing Silicone Rubber YC.JG.MY000397 $0.95 | $0.95 | |
| 2 | Screw M30-HC060060-55-85 YC.WJ.L00870 $2.05 | $2.05 | |
| 3 | ESC Module BC.AG.SS000700 $749.00 | $749.00 | |
| 4 | Cable Sealing Pad YC.JG.MY000399 $0.95 | $0.95 | |
| 5 | Screw (M50-HF01900080-095050-5103-Y) YC.ST.LL000326 $0.95 | $0.95 | |
| 6 | Hose Rubber Sleeve YC.JG.MY001062 $6.00 | $6.00 | |
| 7 | Motor Base (Upper) YC.JG.QX003096 $35.00 | $35.00 | |
| 9 | Motor Base (Lower) YC.JG.QX003097 $35.00 | $35.00 | |
| 10 | 10033 Propulsion Motor BC.AG.SS000668 $580.00 | $580.00 | |
| 11 | Screw (M20-PC01200100-040010-0323-Y) YC.ST.LL000380 $2.50 | $2.50 | |
| 12 | Screw M25-HC00780040-040020-5108-N YC.ST.LL000122 $2.05 | $2.05 | |
| 13 | Elbow Connector (180 Degrees) YC.JG.CS000020 (now supplied as BC.AG.SS000986) $26.00 | $26.00 | |
| 14 | Hose Nut (M15) YC.JG.ZS003460 $2.50 | $2.50 | |
| 15 | Lower Propeller Adapter YC.JG.QX002177 $130.20 | $130.20 | |
| 16 | Motor Cover YC.JG.FP000028 $22.00 | $22.00 | |
| 17 | M30-HT01930060-110025-5103-Y YC.WJ.LL000213 $3.05 | $3.05 | |
| 18 | Screw (M20-PC01200100-040010-0323-Y) YC.ST.LL000380 $2.50 | $2.50 | |
| 19 | M20-TC00700060-033010-0004-Y YC.ST.LL000208 $0.95 | $0.95 | |
| 20 | Motor Upper Cover YC.JG.ZS002379 $11.00 | $11.00 | |
| 21 | Screw M30-HC100100-55-85 YC.WJ.L00871 $2.05 | $2.05 | |
| 22 | M3 Nut YC.WJ.L00877 $2.05 | $2.05 | |
| 23 | Anti-Wear Sleeve YC.JG.ZS003557 $13.00 | $13.00 | |
| 24 | Screw M30-HC100100-55-85 YC.WJ.L00871 $2.05 | $2.05 | |
| 25 | Aircraft Arm Fixing Screw YC.JG.LD000039 $4.40 | $4.40 | |
| 26 | In-Position Detector Bracket YC.JG.ZS002278 $11.00 | $11.00 | |
| 27 | Aircraft Arm Fixing Screw Bolt YC.JG.QX002314 $32.00 | $32.00 | |
| 28 | Aircraft Arm Hose YC.JG.JS000030 $23.90 | $23.90 | |
| 29 | M3 Aircraft Arm (Rear Left) BC.AG.SS000698 (now supplied as BC.AG.SS000846) $469.00 | $469.00 | |
| 30 | Thumb Nut YC.JG.ZS003594 $6.00 | $6.00 | |
| 31 | M3&M4 Aircraft Arm ESC Composite Cable YC.XC.DD000572 $359.00 | $359.00 | |
| 32 | Locking Piece Aircraft Arm Shaft YC.JG.QX002089 $13.00 | $13.00 | |
| 33 | Locking Piece Handle YC.JG.QX003012 $35.00 | $35.00 | |
| 34 | Locking Piece Handle Rubber Sleeve YC.JG.ZS003560 $13.00 | $13.00 | |
| 35 | Locking Piece_Handle Connecting Rod Shaft YC.JG.QX001243 (now supplied as YC.JG.QX004662) $16.00 | $16.00 | |
| 36 | Buckle Module BC.AG.SS000701 $2.50 | $2.50 | |
| 37 | E-Shaped Circlip (6 mm) YC.JG.BJ002409 $2.50 | $2.50 | |
| 38 | Buckle Torsion Spring YC.JG.TT000165 $2.50 | $2.50 | |
| 39 | Buckle Rotation Shaft YC.JG.QX003014 $56.80 | $56.80 | |
| 40 | M40-HC01400140-070039-4105-Y YC.ST.LL000148 $11.95 | $11.95 | |
| 41 | Locking Piece Fixing Screw Bolt YC.JG.LD000041 $9.00 | $9.00 | |
| 42 | M60-HX100060-5103_01 YC.WJ.LM000044 $3.60 | $3.60 | |
| 43 | Locking Piece Connection Rod YC.JG.QX002088 $27.50 | $27.50 | |
| 44 | Screw M40-HC080080-68-85 YC.WJ.L01234 $3.60 | $3.60 | |
| 29 | M4 Aircraft Arm (Rear Right) BC.AG.SS000699 (now supplied as BC.AG.SS000847) $469.00 | $469.00 |
Can't spot your part? Search by part number on the search page or call 1300 916 075.
