DJI Agras T50 Landing Gear

Official DJI parts diagram and material list.

Pricing is per single item unless the part description says otherwise.

All T50 assemblies (15)

Parts Diagram

Hover a number to match it with the list. Double-click or use + to zoom.Tap a number to jump to it in the list. Use + to zoom in.

No.	Part	$ Each (inc. GST)
1	Landing Gear Aluminum Tube YC.JG.BJ001821 $190.00	$190.00
2	Screw M30-HC1880-55-85 YC.WJ.L00873 $3.05	$3.05
3	Landing Gear Bottom Rubber Pad YC.JG.ZS003558 $11.95	$11.95
4	M3 Nut YC.WJ.L00877 $2.05	$2.05
5	Screw M30-HC100100-55-85 YC.WJ.L00871 $2.05	$2.05
6	M3 Nut YC.WJ.L00877 $2.05	$2.05
7	Landing Gear Y-tee Part YC.JG.ZS003468 $6.00	$6.00
8	T30-HC01000100-057030-0323-N YC.WJ.LL000426 $2.50	$2.50
9	Screw M30-HC02800070-055030-0003-Y YC.ST.LL000017 $2.05	$2.05
10	Landing Gear Cable Clip YC.JG.ZS003725 $3.10	$3.10
11	Landing Gear Crossbeam (Rear) YC.JG.XW000110 $75.00	$75.00
12	Landing Gear Fixing Piece (Rear Right) YC.JG.ZS003467 $69.00	$69.00
13	Screw (M40-HC03500120-070040-5103-N) YC.ST.LL000339 $1.25	$1.25
14	M4 Stainless Locknut YC.WJ.L00961 $2.05	$2.05
15	Screw (M40-HC01510056-070039-5103-Y) YC.ST.LL000330 $3.00	$3.00
16	Screw (M40-HC01510056-070039-5103-Y) YC.ST.LL000330 $3.00	$3.00
17	Landing Gear Fixing Piece (Rear Left) YC.JG.ZS003466 $69.00	$69.00
18	Landing Gear Fixing Piece (Front Left) YC.JG.ZS003465 $69.00	$69.00
19	Landing Gear Fixing Piece (Front Right) YC.JG.ZS003464 $69.00	$69.00
20	Landing Gear Crossbeam (Front) YC.JG.XW000111 $75.00	$75.00

Can't spot your part? Search by part number on the search page or call 1300 916 075.
