DJI Agras T70P Spray Tank 1
Official DJI parts diagram and material list.
Pricing is per single item unless the part description says otherwise.
All T70P assemblies (18)
- Spray Tank 1 (38)
- Spray Tank 1 (2) (1)
- Impeller Pump (11)
- Flow Meter (20)
- Omnidirectional Radar Module (1)
- Spray Lance (18)
- Cable Distribution Board (21)
- Front Frame 1 (19)
- Front Frame 2 (31)
- Middle Frame (31)
- Arm 3 (51)
- Landing Gear (43)
- Propellers (12)
- Lifting System Winch (23)
- Misting Spray Lance (18)
- Spreading Spray Tank (25)
- Spreading Spinner Disk (20)
- Spreading Auger (38)
Parts Diagram
Hover a number to match it with the list. Double-click or use + to zoom.Tap a number to jump to it in the list. Use + to zoom in.
| No. | Part | $ Each (inc. GST) | |
|---|---|---|---|
| 3 | Spray Tank Inlet Filter YC.JG.ZS006111 $41.80 | $41.80 | |
| 4 | Vent Trap YC.SJ.S00717 $37.25 | $37.25 | |
| 5 | Dosing Part Rubber Cover YC.JG.MY001721 $28.00 | $28.00 | |
| 6 | Screw M40-HC080080-68-85 YC.WJ.L01234 $3.60 | $3.60 | |
| 7 | Liquid Level Gauge Module BC.AG.SS001122 $153.90 | $153.90 | |
| 9 | Liquid Level Gauge External Hose YC.JG.JS000085 $3.10 | $3.10 | |
| 10 | Liquid Level Gauge Signal Cable YC.XC.XX001397 $45.00 | $45.00 | |
| 11 | Liquid Level Gauge Hose Module BC.AG.SS001121 $34.60 | $34.60 | |
| 12 | Liquid Level Gauge External Hose Rubber Stopper YC.JG.ZS006843 $7.55 | $7.55 | |
| 13 | Spraying Payload Module BC.AG.SS001030 $235.00 | $235.00 | |
| 14 | Screw M40-HC080080-68-85 YC.WJ.L01234 $3.60 | $3.60 | |
| 15 | Socket Rubber Stopper YC.JG.MY001832 $4.00 | $4.00 | |
| 16 | Liquid Level Gauge Base Sealing Ring YC.JG.MY001801 $1.55 | $1.55 | |
| 17 | Liquid Level Gauge Nut YC.JG.ZS004726 $14.00 | $14.00 | |
| 18 | Liquid Level Gauge Base YC.JG.ZS006114 $28.60 | $28.60 | |
| 19 | Screw M40-HC080080-68-85 YC.WJ.L01234 $3.60 | $3.60 | |
| 20 | Impeller Pump Bracket YC.JG.ZS006360 $13.55 | $13.55 | |
| 21 | Payload Adapter Cable YC.XC.DD000798 $148.00 | $148.00 | |
| 22 | Screw M40-HC080080-68-85 YC.WJ.L01234 $3.60 | $3.60 | |
| 23 | Impeller Pump Bracket YC.JG.ZS006360 $13.55 | $13.55 | |
| 24 | Spray Tank Y-tee Part Nut YC.JG.ZS005453 $5.75 | $5.75 | |
| 25 | Screw (M40-HC00600060-120030-0003-N) YC.ST.LL000668 $2.00 | $2.00 | |
| 26 | Spray Tank Rear Support Pad YC.JG.MY001727 $24.00 | $24.00 | |
| 27 | Filter Rubber Ring YC.SJ.J01186 $5.85 | $5.85 | |
| 28 | Spray Tank Y-tee Part Sealing Ring YC.JG.MY000687 $3.80 | $3.80 | |
| 29 | Filter With 50 Holes YC.JG.ZS005454 $35.15 | $35.15 | |
| 30 | Screw (M40-HC00600060-120030-0003-N) YC.ST.LL000668 $2.00 | $2.00 | |
| 31 | Screw (M25-HCW00960040-055020-5103-Y) YC.ST.LL000698 $0.65 | $0.65 | |
| 32 | Spray Tank Side Support Pad YC.JG.MY001728 $5.00 | $5.00 | |
| 33 | Delivery Pump Flow Meter Cable YC.XC.XX001395 $92.00 | $92.00 | |
| 34 | Spray Tank Y-tee Part YC.JG.ZS002232 $21.90 | $21.90 | |
| 35 | Spray Tank Y-tee Part Sealing Ring YC.JG.MY000687 $3.80 | $3.80 | |
| 36 | Damping Rubber Pad YC.JG.MY000845 $0.95 | $0.95 | |
| 37 | Water Outlet Rotation Cover YC.JG.ZS002233 $9.50 | $9.50 | |
| 38 | Spray Tank Cover Sealing Ring YC.JG.MY001720 $22.55 | $22.55 | |
| 39 | Spray Tank Cover YC.JG.ZS006110 $28.60 | $28.60 | |
| 40 | Spray Tank Cover Waterproof Permeability Film YC.JG.MY000678 $2.85 | $2.85 | |
| 41 | Spray Tank Cover Waterproof Permeability Cover YC.JG.ZS002250 $0.95 | $0.95 |
Can't spot your part? Search by part number on the search page or call 1300 916 075.
