DJI Agras T70P Middle Frame
Official DJI parts diagram and material list.
Pricing is per single item unless the part description says otherwise.
All T70P assemblies (18)
- Spray Tank 1 (38)
- Spray Tank 1 (2) (1)
- Impeller Pump (11)
- Flow Meter (20)
- Omnidirectional Radar Module (1)
- Spray Lance (18)
- Cable Distribution Board (21)
- Front Frame 1 (19)
- Front Frame 2 (31)
- Middle Frame (31)
- Arm 3 (51)
- Landing Gear (43)
- Propellers (12)
- Lifting System Winch (23)
- Misting Spray Lance (18)
- Spreading Spray Tank (25)
- Spreading Spinner Disk (20)
- Spreading Auger (38)
Parts Diagram
Hover a number to match it with the list. Double-click or use + to zoom.Tap a number to jump to it in the list. Use + to zoom in.
| No. | Part | $ Each (inc. GST) | |
|---|---|---|---|
| 1 | Power Distribution Board Supporting Piece YC.JG.ZS005318 $45.00 | $45.00 | |
| 2 | M2 Aircraft Arm Connector BC.AG.SS000901 $333.00 | $333.00 | |
| 3 | Cable Tube YC.JG.ZS006286 $30.00 | $30.00 | |
| 4 | Pipe clip YC.JG.ZS006927 $4.00 | $4.00 | |
| 5 | Left Battery Slider Module BC.AG.SS001040 $148.00 | $148.00 | |
| 6 | Screw M50-HC01300112-087052-4203-Y YC.ST.LL000485 $8.00 | $8.00 | |
| 7 | Roller Shaft YC.JG.QX004396 $4.00 | $4.00 | |
| 8 | Screw M50-HC01300112-087052-4203-Y YC.ST.LL000485 $8.00 | $8.00 | |
| 9 | Roller YC.JG.ZS006300 $10.00 | $10.00 | |
| 10 | Middle Frame Aluminum Tube (Left) BC.AG.SS001051 $173.00 | $173.00 | |
| 11 | Aircraft Arm Fixing Piece (Front Left) YC.JG.ZS006121 $39.00 | $39.00 | |
| 12 | Screw M50-HC01300112-087052-4203-Y YC.ST.LL000485 $8.00 | $8.00 | |
| 13 | M3 Aircraft Arm Connector BC.AG.SS001037 $333.00 | $333.00 | |
| 14 | Aircraft Arm Fixing Piece (Rear Left) YC.JG.ZS006124 $19.00 | $19.00 | |
| 15 | Screw M50-HC01300112-087052-4203-Y YC.ST.LL000485 $8.00 | $8.00 | |
| 16 | M4 Aircraft Arm Connector BC.AG.SS001038 $333.00 | $333.00 | |
| 17 | Screw M30-HC100100-55-85 YC.WJ.L00871 $2.05 | $2.05 | |
| 18 | SDR Antenna Rear Shell YC.JG.ZS006128 $10.00 | $10.00 | |
| 19 | Screw M50-HC01300112-087052-4203-Y YC.ST.LL000485 $8.00 | $8.00 | |
| 20 | Aircraft Arm Fixing Piece (Rear Right) YC.JG.ZS006123 $19.00 | $19.00 | |
| 21 | Screw M50-HC01300112-087052-4203-Y YC.ST.LL000485 $8.00 | $8.00 | |
| 22 | Payload Rear Bracket YC.JG.ZS006125 $30.00 | $30.00 | |
| 23 | Aircraft Arm Fixing Piece (Front Right) YC.JG.ZS006122 $39.00 | $39.00 | |
| 24 | Middle Frame Aluminum Tube (Right) BC.AG.SS001052 $173.00 | $173.00 | |
| 25 | Screw M50-HC01300112-087052-4203-Y YC.ST.LL000485 $8.00 | $8.00 | |
| 26 | Screw M50-HC01300112-087052-4203-Y YC.ST.LL000485 $8.00 | $8.00 | |
| 27 | SDR Antenna (Rear) YC.DZ.AA000556 $61.00 | $61.00 | |
| 28 | Right Battery Slider Module BC.AG.SS001039 $148.00 | $148.00 | |
| 29 | Cable Tube YC.JG.ZS006286 $30.00 | $30.00 | |
| 30 | M1 Aircraft Arm Connector BC.AG.SS000900 $333.00 | $333.00 | |
| 31 | Screw M30-HC100100-55-85 YC.WJ.L00871 $2.05 | $2.05 |
