Spray Tank Y-tee Part (T100/T70P/T50/T25P) YC.JG.ZS002232
Shipping: Small Parcel, $15 Australia-wide
Call AGX Drone Distributors: 1300 916 075
About
Specifications and fitment
Part of the outlet plumbing on DJI Agras T100, T70P, T50 and T25P spray tanks, the Y-tee part is the branched fitting shown on each tank diagram with two sealing rings and the water outlet rotation cover.
| Part number | YC.JG.ZS002232 |
| Fits | DJI Agras T100, T70P, T50, T25P |
| Parts diagram | T100 spray tank (sheet 2), callout 24; T70P spray tank (sheet 1), callout 34; T50 spray tank (sheet 2), callout 17; T25P spray tank (sheet 2), callout 10 |
Spray mix runs through this fitting, so a crack soon shows as drips or a chemical crust under the tank. A hard landing, a knock while the tank is out, or overtightening at reassembly can all cause that damage. Replace it if the body is cracked or a sealing face is chipped.
Fit new Y-tee sealing rings whenever it comes apart, and on the T100, T70P and T25P check the threads of the Y-tee part nut too. Flush clean water through and watch the joint before the first chemical load.
