DJI
Screw - M40-HC02000100-072040-5103-Y (T100) YC.ST.LL000706
Shipping: Small Parcel, $15 Australia-wide
Call AGX Drone Distributors: 1300 916 075
About
Specifications and fitment
This screw, M40-HC02000100-072040-5103-Y, belongs to the spreading weight sensor assembly of the DJI Agras T100. It is pictured in sets of four, laid out beside the buckle hook at callout 10.
| Part number | YC.ST.LL000706 |
| Fits | DJI Agras T100 |
| Parts diagram | T100 spreading weight sensor, callout 11 |
Three different screws appear on this sheet and the codes are easy to confuse: this one is callout 11, while YC.ST.LL000013 is callout 8 and YC.ST.LL000112 is callout 5. The T100 auger sheet adds M40-HC01200120-072040-5103-Y (YC.ST.LL000705), which differs by one block of digits. Go by the callout on the diagram rather than by eye when ordering, and count how many you need.
Replace any with a rounded drive, a damaged thread or corrosion, and check the buckle hook drawn beside them for cracks while you are there.
