DJI
M2 & M4 Small Aircraft Arm (T100) BC.AG.SS001101
Shipping: Standard Parcel, $27 Australia-wide
Call AGX Drone Distributors: 1300 916 075
About
Specifications and fitment
For the M2 and M4 positions on a DJI Agras T100, this small aircraft arm is the counterpart to the M1/M3 arm and carries its own part number.
| Part number | BC.AG.SS001101 |
| Fits | DJI Agras T100 |
| Parts diagram | T100 M2/M4 small arm, callout 7 |
DJI draws both small arms on one sheet, with this arm as the alternative to the M1/M3 arm at callout 7 (EE Group's item 7-2); the ESC, buckle hardware, end cap, pads and cables on that sheet fit either arm. DJI's T100 manual puts M2 at the front and M4 at the rear, so this arm takes the front signal and propulsion cables at M2 and the rear ones at M4.
Arms are position-specific. The M1 and M3 small aircraft arm is BC.AG.SS001100 and this one is BC.AG.SS001101, so check the M number marked on the aircraft at the damaged arm before ordering. Cracks, a bend or twist along its length, or a fold that no longer seats and latches squarely all call for a new arm.
