DJI
Spray Lance Shaft (T100) YC.JG.QX004533
Shipping: Small Parcel, $15 Australia-wide
Call AGX Drone Distributors: 1300 916 075
About
Specifications and fitment
Both the standard DJI Agras T100 spray lance and the T100 mist kit's mist spray boom use this spray lance shaft, drawn at callout 16 and callout 13 on their DJI sheets.
| Part number | YC.JG.QX004533 |
| Fits | DJI Agras T100 |
| Parts diagram | T100 spray lance, callout 16; T100 mist kit mist spray boom, callout 13 |
Despite the name, DJI's parts photo shows a short metal pin, roughly 5.5 cm long against the photo's ruler, with a round head at one end and a short thread at the other. It is laid out beside a nylon-insert hex nut, the M60-HX100060-5103_01 nut at callout 15, and level with the angled, bushed lower end of the shaft sleeve (callout 14).
Replace a pin that is bent, scored or worn along its smooth section, or has a damaged thread. Sight along it or hold it against a straight edge to check for a bend, and fit a new nut if its insert no longer grips. The shaft connector (callout 18) is worth checking for cracks while the lance is apart.
