DJI
Spray Lance Shaft Sleeve (T100) YC.JG.ZS006357
Shipping: Small Parcel, $15 Australia-wide
Call AGX Drone Distributors: 1300 916 075
About
Specifications and fitment
Part of the DJI Agras T100 spray lance, the shaft sleeve is drawn at callout 14 on DJI's spray lance sheet. The T100 mist kit's mist spray boom takes the same sleeve, at callout 11 next to the spray lance slider.
| Part number | YC.JG.ZS006357 |
| Fits | DJI Agras T100 |
| Parts diagram | T100 spray lance, callout 14; T100 mist kit mist spray boom, callout 11 |
In DJI's parts photo the sleeve is a black moulding with a ribbed upper section and an angled lower end carrying a round bore lined with a metal bush. The spray lance shaft (callout 16), a short headed pin, is laid out level with that end, with a nylon-insert nut (callout 15) just above it.
Replace the sleeve if the body has cracked, the ribbed section is broken, or the bore is worn oval or scored. While the lance is apart, check the pin and nut as well. Rinsing the lance with clean water after each spraying day stops dried product building up.
