DJI
RTK Antenna Module (T50) BC.AG.SS000694
Shipping: Small Parcel, $15 Australia-wide
Call AGX Drone Distributors: 1300 916 075
About
Specifications and fitment
The DJI Agras T50 carries its RTK antenna module in the rear frame; the module appears at callout 20 on that sheet, beside the glue baffle plate at 19, with the RTK rubber ring at 23.
| Part number | BC.AG.SS000694 |
| Fits | DJI Agras T50 |
| Parts diagram | T50 rear frame, callout 20 |
A weak or dropping RTK fix is not always the antenna. Check the RTK source settings, the base station or network connection and the antenna plug first, then have the module tested at our Horsham or Manjimup workshop before replacing it. Fit a fresh RTK rubber ring if the old one is flattened or torn.
This T50 module is BC.AG.SS000694. The T100, T70P and T25P share a different RTK antenna module, BC.AG.SS001034, which is not the part for a T50.
