DJI
Impeller Pump Bracket (T50/T25P) YC.JG.ZS003392
Shipping: Small Parcel, $15 Australia-wide
Call AGX Drone Distributors: 1300 916 075
About
Specifications and fitment
On the DJI Agras T50 and T25P, this bracket holds an impeller pump in the spray tank assembly. T50 tank 2 numbers it 2, and T25P tank sheet 2 numbers it 8.
| Part number | YC.JG.ZS003392 |
| Fits | DJI Agras T50, T25P |
| Parts diagram | T50 tank 2, callout 2; T25P tank (sheet 2), callout 8 |
Every flight shakes the pump against this bracket, so look for cracks running from the screw holes, holes worn oval, and a pump that shifts when pushed by hand. A pump that is not held firmly strains its hose joints and can start a leak.
The M40-HC060060-55-85 screws drawn next to it on both sheets are sold separately. The T100 and T70P use a different impeller pump bracket, YC.JG.ZS006360.
