DJI
Rear Frame Aluminum Tube (T50) BC.AG.SS000692
Shipping: Standard Parcel, $27 Australia-wide
Call AGX Drone Distributors: 1300 916 075
About
Specifications and fitment
This aluminium tube is part of the DJI Agras T50 rear frame and sits at callout 13 on that sheet, next to the spraying adaptive cable and its rubber sleeve.
| Part number | BC.AG.SS000692 |
| Fits | DJI Agras T50 |
| Parts diagram | T50 rear frame, callout 13 |
Inspect it after any hard landing or strike at the back of the aircraft. A dent, a visible bend, cracking around the clamp points or screw holes that have worn oval are all reasons to replace it, because a bent tube pulls whatever is mounted on it out of line. Frame damage is best assessed before ordering, and our Horsham or Manjimup workshop can look it over.
The T100 rear frame aluminium tube is BC.AG.SS001106 and the T70P version is BC.AG.SS001050, so this one suits the T50 alone.
