Middle Frame Aluminum Tube - Left (T50) BC.AG.SS000687
Shipping: Standard Parcel, $27 Australia-wide
Call AGX Drone Distributors: 1300 916 075
About
Specifications and fitment
Paired with a right-hand tube in the DJI Agras T50 middle frame, this left-hand aluminium tube is shown at callout 8 on the middle frame sheet.
| Part number | BC.AG.SS000687 |
| Fits | DJI Agras T50 |
| Parts diagram | T50 middle frame, callout 8 |
It is drawn next to the M3 aircraft arm connector and the cable clip. After a crash, sight along the tube for a bow, check the ends and fixing points for cracking, and see whether the arm connectors still sit square. Before taking the frame apart, photograph how the cables and hoses run so they go back the same way, or leave the job to our Horsham or Manjimup workshop.
Other models use their own tube: the T100 left tube is BC.AG.SS001104 and the T70P left tube is BC.AG.SS001051.
